| PartNumber | T420HW06 V5 |
| Marca | AUO |
| mărimea | 42 |
| Aplicație | LCTV |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 4000:1 |
| Culori | 1.07B |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | T420HW06 V5 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 42 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | AMVA3, Normally Black, Transmissive |
| Zonă activă | 930.24×523.26 mm |
| contur | 983×576 mm |
| suprafaţă | Antiglare (Haze 11%), Hard coating (3H) |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 4000:1 (Typ.) |
| culorile afișajului | 1.07B (8-bit + Hi-FRC), CIE193172% |
| timp de raspuns | 6.5 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 120Hz (60Hz Input) |
| tip lampa | 10 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (2 ch, 10-bit), 51 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | LCTV |
| T420HVN01.0 | AUO | 42 | 1920×1080 |
| T420HVN02.1 | AUO | 42 | 1920×1080 |
| T420HVN04.5 CELL | AUO | 42 | 1920×1080 |
| T420HW02 V0 | AUO | 42 | 1920×1080 |
| T420HW04 V2 | AUO | 42 | 1920×1080 |
| T420HW06 V0 | AUO | 42 | 1920×1080 |
| T420HW07 V4 | AUO | 42 | 1920×1080 |
| T420HW07 V7 | AUO | 42 | 1920×1080 |
| T420HW08 V9 | AUO | 42 | 1920×1080 |
| T420HW09 V1 | AUO | 42 | 1920×1080 |
| LC420EUF-SCA1 | LG Display | 42 | 1920×1080 |
| LC420WX8-SLA1 | LG Display | 42 | 1366×768 |
| LC470EUN-SDF1 | LG Display | 47 | 1920×1080 |
| LC720DUC-SDF1 | LG Display | 72 | 1920×1080 |
| LTA400HM09 | Samsung | 40 | 1920×1080 |
| LTA460HB08 | Samsung | 46 | 1920×1080 |
| LTY320AP04 | Samsung | 31.5 | 1366×768 |
| T390HVN04.3 CELL | AUO | 39 | 1920×1080 |
| T550HVN02.1 | AUO | 55 | 1920×1080 |
| V236BJ1-P03 | Innolux | 23.6 | 1366×768 |
