| PartNumber | SP10Q010 |
| Marca | KOE |
| mărimea | 3.8 |
| Aplicație | IA |
| Rezoluţie | 320×240 |
| Compoziţie | LCM |
| Luminozitate | 110 |
| CR | 20:1 |
| Culori | Monochrome |
| Iluminare de fundal | WLED |
| Interfață | Parallel Data |
| marca panoului | KOE |
| model de panou | SP10Q010 |
| tip panou | FSTN-LCD , LCM |
| dimensiunea panoului | 3.8 inch |
| rezoluţie | 320×240 , QVGA |
| modul de afișare | STN, Black/White (Negative), Transmissive |
| Zonă activă | 76.79×57.59 mm |
| contur | 94.7×73.3×6 mm |
| suprafaţă | Glare (Haze 0%) |
| luminozitatea | 110 cd/m² (Typ.) |
| Raport de contrast | 20:1 (Typ.) |
| culorile afișajului | Monochrome |
| timp de raspuns | 150/350 (Typ.)(Tr/Td) |
| unghi de vedere | 80 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| frecvență | 75Hz |
| tip lampa | 1S6PWLEDWithout Driver |
| interfață de semnal | Parallel Data (4-bit), 20 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
