| PartNumber | RGC11096096YR000 |
| Marca | RiTdisplay |
| mărimea | 1.1 |
| Aplicație | IA |
| Rezoluţie | 96×96 |
| Compoziţie | OLED |
| Luminozitate | 80 |
| CR | 2000:1 |
| Culori | Mono(Yellow) |
| Iluminare de fundal | self |
| Interfață | CPU/SPI/I²C |
| marca panoului | RiTdisplay |
| model de panou | RGC11096096YR000 |
| tip panou | PM-OLED , OLED |
| dimensiunea panoului | 1.1 inch |
| rezoluţie | 96×96 |
| Zonă activă | 20.14×20.14 mm |
| contur | 27×27×1.71 mm |
| suprafaţă | Antiglare |
| luminozitatea | 80 cd/m² (Typ.) |
| Raport de contrast | 2000 : 1 (Min.) |
| culorile afișajului | Mono(Yellow) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 105Hz |
| driver ic | COG Built-in SSD1327 |
| interfață de semnal | 8-bit 6800/8080 parallel, 3/4-wire SPI, I²C, 24 pins |
| tensiune de intrare | 2.5/3.5/13.0V (Typ.)(VDD/VCI/VCC) |
| aplicarea | IA |
