| PartNumber | QD14XL20 Rev.03 |
| Marca | QDI |
| mărimea | 14.1 |
| Aplicație | NBPC |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM |
| Luminozitate | 185 |
| CR | 300:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | QDI |
| model de panou | QD14XL20 Rev.03 1 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 14.1 inch |
| rezoluţie | 1024(RGB)×768 , XGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 285.696×214.272 mm |
| contur | 299×240.6×5.5 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Antiglare, Hard coating (3H), Reflection 5.0% (Max.) |
| luminozitatea | 185 cd/m² (Typ.) |
| Raport de contrast | 300:1 (Min.) |
| culorile afișajului | 262K (6-bit), CIE193142% |
| timp de raspuns | 10/15 (Typ.)(Tr/Td) |
| unghi de vedere | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (1 ch, 6-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| B141EW04 V4 | AUO | 14.1 | 1280×800 |
| B141EW04 V5 | AUO | 14.1 | 1280×800 |
| HT141WXB-100 | BOE | 14.1 | 1280×800 |
| LP141WP2-TLA1 | LG Display | 14.1 | 1440×900 |
| LP141WP2-TPA1 | LG Display | 14.1 | 1440×900 |
| LTN141AT08-304 | Samsung | 14.1 | 1280×800 |
| LTN141AT09-201 | Samsung | 14.1 | 1280×800 |
| LTN141W1-L09-1 | Samsung | 14.1 | 1280×800 |
| N141I3-L05 | Innolux | 14.1 | 1280×800 |
| QD14XL20 Rev.03 | QDI | 14.1 | 1024×768 |
| CLAA154WA05A | CPT | 15.4 | 1280×800 |
| HSD110PHW2-A00 | HannStar | 11.0 | 1366×768 |
| LP140WH1-TLE3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLM1 | LG Display | 14.0 | 1366×768 |
| LT121EE16000 | TOSHIBA | 12.1 | 1280×800 |
| LTD111EV8X | TOSHIBA | 11.1 | 1366×768 |
| LTD121EQ3B | TOSHIBA | 12.1 | 1280×800 |
| LTD121EXFV | TOSHIBA | 12.1 | 1280×768 |
| LTM09C362F | TOSHIBA | 8.9 | 1024×600 |
| LTN154X3-L0D-G | Samsung | 15.4 | 1280×800 |
