| PartNumber | NL256204AM15-02A |
| Marca | NLT |
| mărimea | 20.1 |
| Aplicație | DMPC |
| Rezoluţie | 2560×2048 |
| Compoziţie | LCM |
| Luminozitate | 850 |
| CR | 600:1 |
| Culori | Grayscale |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | NEC |
| model de panou | NL256204AM15-02A |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 20.1 inch |
| rezoluţie | 2560(LCR)×2048 , QSXGA |
| modul de afișare | SA-SFT, Normally Black, Transmissive |
| Zonă activă | 399.36×319.49 mm |
| contur | 423.4×343.5×45.5 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 850 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | Grayscale (8-bit) |
| timp de raspuns | 15/15 (Typ.)(Tr/Td) |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 12 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (4 ch, 8-bit) |
| tensiune de intrare | 12.0V (Typ.) |
| rohs: | |
| aplicarea | DMPC |
