| PartNumber | NL10276AC24-05 |
| Marca | NLT |
| mărimea | 12.1 |
| Aplicație | DMPC |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 150:1 |
| Culori | Full color |
| Iluminare de fundal | CCFL |
| Interfață | Analog |
| marca panoului | NEC |
| model de panou | NL10276AC24-05 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 12.1 inch |
| rezoluţie | 1024(RGB)×768 , XGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 245.76×184.32 mm |
| contur | 290×225×17 mm |
| suprafaţă | |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 150:1 (Typ.) |
| culorile afișajului | Full color , CIE193140% |
| timp de raspuns | 40 (Max.)(Tr) |
| unghi de vedere | 50/50/20/20 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 2 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | Analog RGB, 31 pins |
| tensiune de intrare | 3.3/12V (Typ.)(VCC/VDD) |
| aplicarea | DMPC |
| NL10276AC24-05 | NLT | 12.1 | 1024×768 |
| NL10276AC30-04R | NLT | 15.0 | 1024×768 |
| NL10276BC12-02 | NLT | 6.3 | 1024×768 |
| NL10276BC13-01C | NLT | 6.5 | 1024×768 |
| NL10276BC16-01 | NLT | 8.4 | 1024×768 |
| NL10276BC16-06D | NLT | 8.4 | 1024×768 |
| NL10276BC20-04 | NLT | 10.4 | 1024×768 |
| NL10276BC24-21 | NLT | 12.1 | 1024×768 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| NL10276BC30-39 | NLT | 15.0 | 1024×768 |
| LM170E03-TLL1 | LG Display | 17.0 | 1280×1024 |
| LM240WU2-SLB1 | LG Display | 24.0 | 1920×1200 |
| LTM190BT03 | Samsung | 19.0 | 1440×900 |
| LTM190BT07 | Samsung | 19.0 | 1440×900 |
| LTM200KT08-V | Samsung | 20.0 | 1600×900 |
| LTM201M1-L01 | Samsung | 20.1 | 1680×1050 |
| LTM240CT06 | Samsung | 24.0 | 1920×1200 |
| M270HVN02.0 | AUO | 27.0 | 1920×1080 |
| MT190AW01 V.7 | Innolux | 19.0 | 1440×900 |
| MT215DW01 V.1 | Innolux | 21.5 | 1920×1080 |
