| PartNumber | ND078-101A1 |
| Marca | SEBO |
| mărimea | 7.8 |
| Aplicație | CNS |
| Rezoluţie | 1280×400 |
| Compoziţie | LCM |
| Luminozitate | 700 |
| CR | 900:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | SEBO |
| model de panou | ND078-101A1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.8 inch |
| rezoluţie | 1280(RGB)×400 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 190.08×59.4 mm |
| contur | 205.78×67.8×7.25 mm |
| suprafaţă | |
| luminozitatea | 700 cd/m² (Typ.) |
| Raport de contrast | 900:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193160% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S6PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 1.5/3.3/10/19/-8V (Typ.)(VCC/VDD/AVDD/VGH/VGL) |
| aplicarea | CNS |
| 70WVW1T | SII | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| DLC1040ABG-T-2 | Other | 10.4 | 800×600 |
| G070Y1-T01 | Innolux | 7.0 | 800×480 |
| L5F30614T23 | SANYO | 8.0 | 800×480 |
| LAJ080W001A | TPO | 8.0 | 800×480 |
| LQ042B5DG02 | SHARP | 4.2 | 400×96 |
| LQ050T5DG02 | SHARP | 5.0 | 400×240 |
| PA079DS1T3 | E Ink | 7.9 | 480×234 |
| YXDK050TN02-40NM03 | SEBO | 5.0 | 800×480 |
