| PartNumber | N133BGE-EB1 |
| Marca | Innolux |
| mărimea | 13.3 |
| Aplicație | NBPC |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 650:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca panoului | INNOLUX |
| model de panou | N133BGE-EB1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 13.3 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 293.42×164.97 mm |
| contur | 306.3×189.15×2.85 mm |
| stilul formei | Slim (PCBA Flat, Depth ≤3.2mm) |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 650:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193150% |
| timp de raspuns | 3/8 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | eDP (1 Lane), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| N133B6-L01 | Innolux | 13.3 | 1366×768 |
| N133B6-L02 | Innolux | 13.3 | 1366×768 |
| N133BGE-E31 | Innolux | 13.3 | 1366×768 |
| N133BGE-E51 | Innolux | 13.3 | 1366×768 |
| N133BGE-EAB | Innolux | 13.3 | 1366×768 |
| N133BGE-EB1 | Innolux | 13.3 | 1366×768 |
| N133BGE-L21 | Innolux | 13.3 | 1366×768 |
| N133BGE-L31 | Innolux | 13.3 | 1366×768 |
| N133BGE-L41 | Innolux | 13.3 | 1366×768 |
| N133BGE-LB1 | Innolux | 13.3 | 1366×768 |
| B140XTN03.3 HW0A | AUO | 14.0 | 1366×768 |
| HSD173PUW1-A01 | HannStar | 17.3 | 1920×1080 |
| LP133WH1-TLA1 | LG Display | 13.3 | 1366×768 |
| LP133WX2-TLAA | LG Display | 13.3 | 1280×800 |
| LP140WH4-TLP1 | LG Display | 14.0 | 1366×768 |
| LTD133EX3X | TOSHIBA | 13.3 | 1280×800 |
| LTM14C421F | TOSHIBA | 14.1 | 1024×768 |
| LTN121AP03-001 | Samsung | 12.1 | 1280×800 |
| LTN140AT07-T01 | Samsung | 14.0 | 1366×768 |
| M101NWN8 R0 | IVO | 10.1 | 1366×768 |
