| PartNumber | N116HSE-EA1 |
| Marca | Innolux |
| mărimea | 11.6 |
| Aplicație | NBPC |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 350 |
| CR | 700:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca panoului | CHIMEI INNOLUX |
| model de panou | N116HSE-EA1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 11.6 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | AAS, Normally Black, Transmissive |
| Zonă activă | 256.32×144.18 mm |
| contur | 278×166×3.07 mm |
| stilul formei | Slim (PCBA Flat, Depth ≤3.2mm) |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 700:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 14/11 (Typ.)(Tr/Td) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | eDP (2 Lanes), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| B116AW02 V0 | AUO | 11.6 | 1024×600 |
| B116HAN03.1 | AUO | 11.6 | 1920×1080 |
| LP116WH1-TLN1 | LG Display | 11.6 | 1366×768 |
| LTN116AT01-401 | Samsung | 11.6 | 1366×768 |
| M116NWR1 R7 | IVO | 11.6 | 1366×768 |
| N116HSE-EA1 | Innolux | 11.6 | 1920×1080 |
| N116HSE-EA2 | Innolux | 11.6 | 1920×1080 |
| N116HSE-EBC | Innolux | 11.6 | 1920×1080 |
| N116HSE-EJ1 | Innolux | 11.6 | 1920×1080 |
| VVX11F019G00 | Panasonic | 11.6 | 1920×1080 |
| B125HAN02.0 | AUO | 12.5 | 1920×1080 |
| LP133WH2-TLM2 | LG Display | 13.3 | 1366×768 |
| LP140WH4-TLA1 | LG Display | 14.0 | 1366×768 |
| LP154WU1-TLC1 | LG Display | 15.4 | 1920×1200 |
| LP156WH2-TLR1 | LG Display | 15.6 | 1366×768 |
| LP171WE3-TLA2 | LG Display | 17.1 | 1680×1050 |
| LP171WP6-TL04 | LG Display | 17.1 | 1440×900 |
| LT133X8-122 | Samsung | 13.3 | 1024×768 |
| LTN140AT07-306 | Samsung | 14.0 | 1366×768 |
| N156HCA-EA1 | Innolux | 15.6 | 1920×1080 |
