Innolux MT190AW02 V.A fișă de date, specificație, stocuri, aplicație www.looklcd-ro.com
LookLCD LookLCD


MT190AW02 V.A

MT190AW02 V.A
MT190AW02 V.A thumb
Marca
Innolux
mărimea
19.0
Aplicație
DMPC
Rezoluţie
1440×900
Compoziţie
LCM
Luminozitate
250
CR
1000:1
Culori
16.7M
Iluminare de fundal
CCFL
Interfață
LVDS
In Stock
7525
Specificații

PartNumber MT190AW02 V.A
MarcaInnolux
mărimea19.0
AplicațieDMPC
Rezoluţie1440×900
CompoziţieLCM
Luminozitate250
CR1000:1
Culori16.7M
Iluminare de fundalCCFL
InterfațăLVDS
marca panouluiINNOLUX
model de panouMT190AW02 V.A
tip panou a-Si TFT-LCD , LCM
dimensiunea panoului19.0 inch
rezoluţie1440(RGB)×900 , WXGA+
modul de afișareTN, Normally White, Transmissive
Zonă activă408.24×255.15 mm
contur428×278×16.5 mm
suprafaţăAntiglare (Haze 25%), Hard coating (3H)
luminozitatea250 cd/m² (Typ.)
Raport de contrast1000:1 (Typ.)
culorile afișajului16.7M (6-bit + Hi-FRC), CIE193172%
timp de raspuns1.5/3.5 (Typ.)(Tr/Td)
unghi de vedere80/80/80/80 (Typ.)(CR≥10)(L/R/U/D)
frecvență60Hz
tip lampa4 pcsCCFLWithout Driver
interfață de semnalLVDS (2 ch, 8-bit), 30 pins
tensiune de intrare5.0V (Typ.)
aplicareaDMPC
