| PartNumber | M238DTN01.3 |
| Marca | AUO |
| mărimea | 23.8 |
| Aplicație | Desktop Monitor Gami |
| Rezoluţie | 2560×1440 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca | AUO |
| model | M238DTN01.3 |
| dimensiunea diagonalei | 23.8 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 2560(RGB)×1440 [Quad-HD] 123PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 526.85(H)×296.35(V) mm |
| contur dim. | 536.9(H)×313.89(V) ×12.7(D) mm |
| zona rama | - |
| tratament | Antiglare, Hard coating (3H) |
| luminanţă | 350 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) (TM) |
| direcția vizualizării | - |
| timp de raspuns | 3.5/1.5 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/80/80 (Typ.)(CR≥10) |
| mod de operare | TN, Normally White, Transmissive |
| culoare suport | 16.7M 72% NTSC |
| sursă de lumină | WLED [16S4P] , 30K hours , W/O Driver |
| greutate | 2.27Kgs (Typ.) |
| proiectat pentru | Desktop Monitor Gaming |
| rata de cadre | 144Hz |
| panou tactil | Without |
| tipul de interfață | LVDS (8 ch, 8-bit) , 130 pins Connector |
| alimentare electrică | 12V (Typ.) |
| mediu inconjurator | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| LM238WF1-SLE1 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSF1 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSG2 | LG Display | 23.8 | 1920×1080 |
| LM238WF4-SSA1 | LG Display | 23.8 | 1920×1080 |
| LM238WQ1-SLA1 | LG Display | 23.8 | 2560×1440 |
| LM238WR2-SLA1 | LG Display | 23.8 | 3840×2160 |
| M238DAN01.1 Q0 | AUO | 23.8 | 2560×1440 |
| M238HAN01.0 | AUO | 23.8 | 1920×1080 |
| MV238FHM-N10 | BOE | 23.8 | 1920×1080 |
| MV238QUM-N20 | BOE | 23.8 | 3840×2160 |
