| PartNumber | LTN140AT02-C02 |
| Marca | Samsung |
| mărimea | 14.0 |
| Aplicație | NBPC |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 220 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | SAMSUNG |
| model de panou | LTN140AT02-C02 1 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 14.0 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 309.399×173.952 mm |
| contur | 323.5×192×5.2 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Glare (Haze 0%), Hard coating (3H) |
| luminozitatea | 220 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Min.) |
| culorile afișajului | 262K (6-bit), CIE193160% |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 7S6PWLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| LTN140AT02-B01 | Samsung | 14.0 | 1366×768 |
| LTN140AT02-C02 | Samsung | 14.0 | 1366×768 |
| LTN140AT11-L02 | Samsung | 14.0 | 1366×768 |
| LTN140AT20-301 | Samsung | 14.0 | 1366×768 |
| LTN140AT20-701 | Samsung | 14.0 | 1366×768 |
| LTN140AT20-L01 | Samsung | 14.0 | 1366×768 |
| LTN140AT20-P02 | Samsung | 14.0 | 1366×768 |
| LTN140AT20-W05 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-B01 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-T01 | Samsung | 14.0 | 1366×768 |
| B170UW01 V0 | AUO | 17.0 | 1920×1200 |
| CLAA133WB01A | CPT | 13.3 | 1366×768 |
| HV133WX1-100 | HYDIS | 13.3 | 1280×800 |
| LP140WHU-TPB2 | LG Display | 14.0 | 1366×768 |
| LP154WX7-TLB3 | LG Display | 15.4 | 1280×800 |
| LQ121X1LH22 | SHARP | 12.1 | 1024×768 |
| LTM10C321N | TOSHIBA | 10.4 | 1024×768 |
| LTN184KT01-A01 | Samsung | 18.4 | 1680×945 |
| N121IB-L04 | Innolux | 12.1 | 1280×800 |
| N156B3-L02 | Innolux | 15.6 | 1366×768 |
