| PartNumber | CLAA133WB01A |
| Marca | CPT |
| mărimea | 13.3 |
| Aplicație | NBPC |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | CPT |
| model de panou | CLAA133WB01A |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 13.3 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 293.42×164.97 mm |
| contur | 314.1×188.96×3.6 mm |
| stilul formei | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| suprafaţă | Glare (Haze 0%) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 8 (Typ.)(G to G) |
| unghi de vedere | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| B133EW04 V4 | AUO | 13.3 | 1280×800 |
| CLAA133UA01 | CPT | 13.3 | 1600×900 |
| CLAA133UA03 | CPT | 13.3 | 1600×900 |
| CLAA133WA01A | CPT | 13.3 | 1366×768 |
| CLAA133WB01A | CPT | 13.3 | 1366×768 |
| LP133WH2-TLM4 | LG Display | 13.3 | 1366×768 |
| LTN133AT01-003 | Samsung | 13.3 | 1280×800 |
| LTN133AT09-W01 | Samsung | 13.3 | 1280×800 |
| LTN133AT23-001 | Samsung | 13.3 | 1366×768 |
| N133HSG-WJ1 | Innolux | 13.3 | 1920×1080 |
| B133EW04 V0 | AUO | 13.3 | 1280×800 |
| B133HAN02.1 | AUO | 13.3 | 1920×1080 |
| B140HTN01.1 | AUO | 14.0 | 1920×1080 |
| B173HW01 V5 | AUO | 17.3 | 1920×1080 |
| HB140WX1-300 | BOE | 14.0 | 1366×768 |
| LP133WX3-TLA4 | LG Display | 13.3 | 1280×800 |
| LP171WX2-A4K1 | LG Display | 17.1 | 1440×900 |
| LTN141BT04-002 | Samsung | 14.1 | 1440×900 |
| LTN160AT01-W01 | Samsung | 16.0 | 1366×768 |
| NV140FHM-N41 | BOE | 14.0 | 1920×1080 |
