| PartNumber | LQ231U1LW01 |
| Marca | SHARP |
| mărimea | 23.1 |
| Aplicație | IA |
| Rezoluţie | 1600×1200 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 500:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | OpenLDI |
| marca panoului | SHARP |
| model de panou | LQ231U1LW01 1 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 23.1 inch |
| rezoluţie | 1600(RGB)×1200 , UXGA |
| modul de afișare | MVA, Normally Black, Transmissive |
| Zonă activă | 470.4×352.8 mm |
| contur | 530×432.8×33.5 mm |
| suprafaţă | Antiglare (Haze 25%), Hard coating (3H) |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 20/10 (Typ.)(Tr/Td); 15 (Typ.)(G to G) |
| unghi de vedere | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| tip lampa | 6 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | OpenLDI, 31 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | IA |
