| PartNumber | LQ110Y1LG12 |
| Marca | SHARP |
| mărimea | 11.0 |
| Aplicație | GM |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 330 |
| CR | 500:1 |
| Culori | 16.2M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | SHARP |
| model de panou | LQ110Y1LG12 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 11.0 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 238.8×143.28 mm |
| contur | 257×164.5×9.9 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 330 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 16.2M (6-bit + FRC), CIE193170% |
| timp de raspuns | 23.0 (Typ.)(Tr+Td) |
| unghi de vedere | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 8-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | GM |
