| PartNumber | LQ108M1JW01 |
| Marca | SHARP |
| mărimea | 10.8 |
| Aplicație | NBPC |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca panoului | SHARP |
| model de panou | LQ108M1JW01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.8 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | Normally Black, Transmissive |
| Zonă activă | 239.04×134.46 mm |
| contur | 250.2×149.1×2.5 mm |
| suprafaţă | Antiglare (Haze 24%), Hard coating (3H) |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 5S8PWLEDWithout Driver |
| interfață de semnal | eDP (4 Lanes), 51 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
