| PartNumber | LPM015M135A |
| Marca | JDI |
| mărimea | 1.5 |
| Aplicație | Wearable |
| Rezoluţie | 200×228 |
| Compoziţie | LCM, LTPS TFT-LCD |
| Luminozitate | |
| CR | 20:1 |
| Culori | 64 |
| Iluminare de fundal | No |
| Interfață | |
| producător | JDI |
| numele modelului | LPM015M135A |
| marimea ecranului | 1.5 inch |
| tipul de ecran | LCM, LTPS TFT-LCD |
| numărul de pixeli | 200(RGB)×228 201PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 25.2 × 28.728 (H×V) |
| contur (mm) | 28 × 33.428 (H×V×D) |
| zona rama (mm) | - |
| tratament | Hard coating (2H) |
| luminanţă | - |
| Raport de contrast | 20:1 (Typ.) (RF) |
| unghi de vedere | 60/65/65/60 (Typ.)(CR≥2) |
| raspuns | 3/6 (Typ.)(Tr/Td) ms |
| vedere buna la | - |
| modul de lucru | ECB, Normally Black, Reflective |
| adâncimea culorii | 64 17% NTSC |
| lumina de fundal | No B/L , No Driver |
| masa | 1.70g (Typ.) |
| folosit pentru | Wearable |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| A015AN04 V6 | AUO | 1.5 | 280×220 |
| LPM010R030B | JDI | 0.99 | 180×180 |
| LPM012A154A | JDI | 1.2 | 218×218 |
| LPM013M091A | JDI | 1.34 | 320×300 |
| OEL9M0039-B-E | Other | 1.5 | 128×128 |
| OEL9M0039-G-E | Other | 1.5 | 128×128 |
| OEL9M0039-Y-E | Other | 1.5 | 128×128 |
| OEL9M1004-L4-E | Other | 1.5 | 128×128 |
| RGS15128128WR000 | RiTdisplay | 1.5 | 128×128 |
| UG-2828GDEDF11 | WiseChip | 1.5 | 128×128 |
