| PartNumber | LP133WX1-TLB1 |
| Marca | LG Display |
| mărimea | 13.3 |
| Aplicație | NBPC |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM |
| Luminozitate | 220 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | LG.Philips LCD |
| model de panou | LP133WX1-TLB1 1 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 13.3 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 286.08×178.8 mm |
| contur | 299×195×5.5 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Antiglare, Hard coating (3H), Antireflection |
| luminozitatea | 220 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Min.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| LP133WH2-TLB2 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL3 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLM4 | LG Display | 13.3 | 1366×768 |
| LP133WP1-TJA1 | LG Display | 13.3 | 1440×900 |
| LP133WP1-TJA7 | LG Display | 13.3 | 1440×900 |
| LP133WQ1-SJEV | LG Display | 13.3 | 2560×1600 |
| LP133WX1-TLA1 | LG Display | 13.3 | 1280×800 |
| LP133WX1-TLN2 | LG Display | 13.3 | 1280×800 |
| LP133WX2-TLG6 | LG Display | 13.3 | 1280×800 |
| LP133WX2-TLGV | LG Display | 13.3 | 1280×800 |
| HSD150PX14-A00 | HannStar | 15.0 | 1024×768 |
| HV150UX2-100 | HYDIS | 15.0 | 1600×1200 |
| LP104V2-W | LG Display | 10.4 | 640×480 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| LP173WD1-TLN4 | LG Display | 17.3 | 1600×900 |
| LTD104EA5R | TOSHIBA | 10.4 | 1024×768 |
| LTN150PG-L04 | Samsung | 15.0 | 1400×1050 |
| N116HSE-EA2 | Innolux | 11.6 | 1920×1080 |
| N156B6-L0A | Innolux | 15.6 | 1366×768 |
| VVX13F009G10 | Panasonic | 13.3 | 1920×1080 |
