| PartNumber | LP125WH2-SLB2 |
| Marca | LG Display |
| mărimea | 12.5 |
| Aplicație | NBPC |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | LG Display |
| model de panou | LP125WH2-SLB2 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 12.5 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 275.59×154.94 mm |
| contur | 290.5×180.9×3.7 mm |
| stilul formei | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| suprafaţă | Antiglare |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Min.) |
| culorile afișajului | 262K (6-bit), CIE193150% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| LP125WF1-SPA2 | LG Display | 12.5 | 1920×1080 |
| LP125WF1-SPD1 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB1 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB3 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLB2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLT1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPT1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLE1 | LG Display | 12.5 | 1366×768 |
| B170UW02 V0 | AUO | 17.0 | 1920×1200 |
| LP140WF6-SPB3 | LG Display | 14.0 | 1920×1080 |
| LP140WH4-TLN1 | LG Display | 14.0 | 1366×768 |
| LP154W01-TLA2 | LG Display | 15.4 | 1280×800 |
| LP154WE3-TLA1 | LG Display | 15.4 | 1680×1050 |
| LQ156D1JW02 | SHARP | 15.6 | 3840×2160 |
| LTM14C421F | TOSHIBA | 14.1 | 1024×768 |
| LTN133AT09-G02 | Samsung | 13.3 | 1280×800 |
| N164HGE-L12 | Innolux | 16.4 | 1920×1080 |
| N173HCE-E31 | Innolux | 17.3 | 1920×1080 |
