| PartNumber | LP079X01-SMA1 |
| Marca | LG Display |
| mărimea | 7.9 |
| Aplicație | PAD |
| Rezoluţie | 768×1024 |
| Compoziţie | LCM |
| Luminozitate | 425 |
| CR | 900:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | LG Display |
| model de panou | LP079X01-SMA1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.9 inch |
| rezoluţie | 768(RGB)×1024 , XGA |
| modul de afișare | AH-IPS, Normally Black, Transmissive |
| Zonă activă | 119.808×159.744 mm |
| contur | 129×171.07×4.81 mm |
| suprafaţă | Glare (Haze 0%), Hard coating |
| luminozitatea | 425 cd/m² (Typ.) |
| Raport de contrast | 900:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 17 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6 stringsWLEDWithout Driver |
| interfață de semnal | MIPI (4 data lanes), 32 pins |
| tensiune de intrare | 3.6V (Typ.) |
| aplicarea | PAD |
