| PartNumber | JJ070IA-18L |
| Marca | Innolux |
| mărimea | 7.0 |
| Aplicație | Automotive Display |
| Rezoluţie | 800×480 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | 7S2P |
| Interfață | LVDS |
| producător | Innolux |
| marimea ecranului | 7.0 inch |
| numărul de pixeli | 800(RGB)×480 (WVGA) 133PPI |
| zona activa (mm) | 152.4 × 91.44 (H×V) |
| zona rama (mm) | 155.4 × 94.44 (H×V) |
| luminanţă | 750 cd/m² (Typ.) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| vedere buna la | Symmetry |
| adâncimea culorii | 16.7M 70% NTSC |
| masa | 195±9g |
| rată de reîmprospătare | 60Hz |
| tipul semnalului | LVDS (1 ch, 8-bit) , 50 pins FPC |
| alimentare cu tensiune | 3.3/13.3/26/-7V (Typ.)(VDD/VDDA/VGH/VGL) |
| max. evaluări | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| numele modelului | JJ070IA-18L |
| tipul de ecran | LCM , a-Si TFT-LCD |
| aranjament | RGB Vertical Stripe |
| contur (mm) | 162.8 × 104.84 (H×V×D) |
| tratament | Antiglare |
| Raport de contrast | 1000 : 1 (Typ.) (TM) |
| raspuns | 15/10 (Typ.)(Tr/Td) ms |
| modul de lucru | IPS, Normally Black, Transmissive |
| lumina de fundal | 7S2P WLED , 20K hours , No Driver |
| folosit pentru | Automotive Display |
| touch screen | Without |
