| PartNumber | HSD101BFW6-A00 |
| Marca | HannStar |
| mărimea | 10.1 |
| Aplicație | Pad & Tablet |
| Rezoluţie | 1024×600 |
| Compoziţie | CELL, a-Si TFT-LCD |
| Luminozitate | |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | No |
| Interfață | |
| producător | HannStar |
| numele modelului | HSD101BFW6-A00 |
| marimea ecranului | 10.1 inch |
| tipul de ecran | CELL, a-Si TFT-LCD |
| numărul de pixeli | 1024(RGB)×600 (WSVGA) 117PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 222.72 × 125.28 (H×V) |
| contur (mm) | 230.4 × 134.2 × 0.8 (H×V×D) |
| luminanţă | 0 cd/m² |
| Raport de contrast | 800 : 1 (Typ.) (TM) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| raspuns | 10/20 (Typ.)(Tr/Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | IPS Pro, Normally Black, Transmissive |
| grosimea sticlei | 0.40+0.40 mm |
| transmisivitatea | 5.81% (Typ.)(with Polarizer) |
| adâncimea culorii | 16.7M 45% NTSC |
| lumina de fundal | No B/L |
| masa | - |
| folosit pentru | Pad & Tablet |
| rată de reîmprospătare | - |
| touch screen | Without |
| lista de drivere ic | Suggest COG EK79007AD, HX8282-C, EK73215BCGA, HX8696-A |
| max. evaluări | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
