| PartNumber | HSD070PFW3-B02 |
| Marca | HannStar |
| mărimea | 7.0 |
| Aplicație | MP4 |
| Rezoluţie | 1024×600 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 800:1 |
| Culori | 16.2M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | HannStar |
| model de panou | HSD070PFW3-B02 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 1024(RGB)×600 , WSVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 153.6×90 mm |
| contur | 165.75×105.39×3.7 mm |
| suprafaţă | |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.2M (6-bit + FRC), CIE193150% |
| timp de raspuns | 4/12 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/70/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S6PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3/11.0/20.0/-6.8V (Typ.)(VDD/AVDD/VGH/VGL) |
| aplicarea | MP4 |
| HSD070PFW1-A00 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-B02 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-C01 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-D00 | HannStar | 7.0 | 1024×600 |
| HSD070PWW1-B01 | HannStar | 7.0 | 1280×800 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
| LQ070T5DR06 | SHARP | 7.0 | 480×240 |
| LQ070Y5DG30 | SHARP | 7.0 | 800×480 |
| LTA070B511F | TOSHIBA | 7.0 | 800×480 |
| PM070WU1 | E Ink | 7.0 | 800×480 |
| AT070TN82 | Innolux | 7.0 | 800×480 |
| CLAA070LC0DCW | CPT | 7.0 | 800×480 |
| CLAA089NA0FCW | CPT | 8.9 | 1024×600 |
| DLC0700MIG | Other | 7.0 | 800×480 |
| HJ070NA-13D | Innolux | 7.0 | 1024×600 |
| HSD070PFW3-B02 | HannStar | 7.0 | 1024×600 |
| LMS700KF07 | Samsung | 7.0 | 800×480 |
| LMS700KF21 | Samsung | 7.0 | 800×480 |
| LTN089NT01 | Samsung | 8.9 | 1024×600 |
| Q070LRE-L81 | Innolux | 7.0 | 1024×600 |
