| PartNumber | G170ETN03.1 |
| Marca | AUO |
| mărimea | 17.0 |
| Aplicație | Industrial |
| Rezoluţie | 1280×1024 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca | AUO |
| model | G170ETN03.1 |
| dimensiunea diagonalei | 17.0 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 1280(RGB)×1024 [SXGA] 96PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 337.92(H)×270.336(V) mm |
| contur dim. | 358.5(H)×296.5(V) ×10.8(D) mm |
| zona rama | 341.7(H)×274.1(V) mm |
| tratament | Antiglare, Hard coating (3H) |
| luminanţă | 400 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) (TM) |
| direcția vizualizării | - |
| timp de raspuns | 3.8/1.2 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/80/80 (Typ.)(CR≥10) |
| mod de operare | TN, Normally White, Transmissive |
| culoare suport | 16.7M 72% NTSC |
| sursă de lumină | WLED [9S4P] , 30K hours , W/O Driver |
| greutate | 1.27Kgs (Typ.) |
| proiectat pentru | Industrial |
| rata de cadre | 60Hz |
| panou tactil | Without |
| tipul de interfață | LVDS (2 ch, 8-bit) , 30 pins Connector |
| alimentare electrică | 5.0V (Typ.) |
| mediu inconjurator | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
