| PartNumber | EV121WXM-N12 |
| Marca | BOE |
| mărimea | 12.1 |
| Aplicație | Medical Imaging |
| Rezoluţie | 1280×800 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 1200:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca | BOE |
| model | EV121WXM-N12 |
| dimensiunea diagonalei | 12.1 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 1280(RGB)×800 [WXGA] 124PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 261.12(H)×163.2(V) mm |
| contur dim. | 277.7(H)×180.6(V) ×9.2(D) mm |
| zona rama | 264.12(H)×166.2(V) mm |
| tratament | Antiglare (Haze 25%) |
| luminanţă | 500 cd/m² (Typ.) |
| Raport de contrast | 1200:1 (Typ.) (TM) |
| direcția vizualizării | Symmetry |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| mod de operare | ADS, Normally Black, Transmissive |
| culoare suport | 262K/16.7M 100% sRGB |
| sursă de lumină | WLED [12S4P] , 50K hours , With LED Driver |
| greutate | TBD |
| proiectat pentru | Medical Imaging |
| rata de cadre | 60Hz |
| panou tactil | Without |
| tipul de interfață | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| alimentare electrică | 3.3V (Typ.) |
| mediu inconjurator | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
