| PartNumber | DLC0700BZG-7 |
| Marca | Other |
| mărimea | 7.0 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 700 |
| CR | 500:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | DLC |
| model de panou | DLC0700BZG-7 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 154.08×85.92 mm |
| contur | 164.2×100 mm |
| suprafaţă | Antiglare |
| luminozitatea | 700 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| timp de raspuns | 10/15 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S10PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6/8-bit), 50 pins |
| tensiune de intrare | 3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplicarea | CNS |
| DLC0700BZG-7 | Other | 7.0 | 800×480 |
| DLC0700CZG-6 | Other | 7.0 | 800×480 |
| DLC0700DDG-4 | Other | 7.0 | 800×480 |
| DLC0700FDG-T-6 | Other | 7.0 | 800×480 |
| DLC0700JBG-T-6 | Other | 7.0 | 1024×600 |
| DLC0700MIG | Other | 7.0 | 800×480 |
| DLC0700OZG-T-1 | Other | 7.0 | 800×480 |
| DLC0700WZG | Other | 7.0 | 1200×1920 |
| DLC0700YZG-1 | Other | 7.0 | 1024×600 |
| DLC0700YZG-T-6 | Other | 7.0 | 1024×600 |
| AC070MD01 | Mitsubishi | 7.0 | 800×480 |
| C070VW04 V7 | AUO | 7.0 | 800×480 |
| CLAA070NJ01CW | CPT | 7.0 | 1024×600 |
| DJ065NA-01C | Innolux | 6.5 | |
| DLC0700EZG-2 | Other | 7.0 | 800×480 |
| L5F30369P01 | SANYO | 6.5 | 800×480 |
| LB058WQ1-SD03 | LG Display | 5.8 | 400×240 |
| LB070WQ5-TD01 | LG Display | 7.0 | 480×240 |
| NL3224AC35-06 | NLT | 5.5 | 320×240 |
| PD050VX6 | E Ink | 5.0 | 640×480 |
