| PartNumber | CLAA101NC05 |
| Marca | CPT |
| mărimea | 10.1 |
| Aplicație | NOPC |
| Rezoluţie | 1024×600 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | CPT |
| model de panou | CLAA101NC05 9 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.1 inch |
| rezoluţie | 1024(RGB)×600 , WSVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 222.72×125.28 mm |
| contur | 235×143×5.2 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 20 (Typ.)(Tr+Td) |
| unghi de vedere | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NOPC |
| CLAA101FP01 XG | CPT | 10.1 | 1920×1200 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| CLAA104XA12BW | CPT | 10.4 | 1024×768 |
| CLAA140UA01 CN | CPT | 14.0 | 1600×900 |
| CLAA140WB11A | CPT | 14.0 | 1366×768 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| CLAA170EA07 | CPT | 17.0 | 1280×1024 |
| CLAA170EA10 | CPT | 17.0 | 1280×1024 |
| CLAA185WA03 | CPT | 18.5 | 1366×768 |
| CLAA185WA04 | CPT | 18.5 | 1366×768 |
| B116XTN01.0 HW5A | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| B116XW02 V1 | AUO | 11.6 | 1366×768 |
| BT101IW04 V.0 | Innolux | 10.1 | 1024×600 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| HSD070PFW1-A00 | HannStar | 7.0 | 1024×600 |
| LP101WS1-TLB3 | LG Display | 10.1 | 1024×576 |
| M101NWT2 R3 | IVO | 10.1 | 1024×600 |
| N101LGE-L41 | Innolux | 10.1 | 1024×600 |
| N116B6-L07 | Innolux | 11.6 | 1366×768 |
