| PartNumber | B141EW05 V4 |
| Marca | AUO |
| mărimea | 14.1 |
| Aplicație | NBPC |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM |
| Luminozitate | 220 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | B141EW05 V4 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 14.1 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 303.36×189.6 mm |
| contur | 319.5×205.5×5.5 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Antiglare |
| luminozitatea | 220 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 6/2 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 7S6PWLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| B141EW01 V3 | AUO | 14.1 | 1280×800 |
| B141EW02 V3 | AUO | 14.1 | 1280×800 |
| B141EW03 V3 | AUO | 14.1 | 1280×800 |
| B141EW04 V0 | AUO | 14.1 | 1280×800 |
| B141EW04 V3 | AUO | 14.1 | 1280×800 |
| B141EW04 V4 | AUO | 14.1 | 1280×800 |
| B141EW04 V5 | AUO | 14.1 | 1280×800 |
| B141EW05 V3 | AUO | 14.1 | 1280×800 |
| B141EW05 V4 | AUO | 14.1 | 1280×800 |
| B141EW05 V5 | AUO | 14.1 | 1280×800 |
| B121EW01 V0 | AUO | 12.1 | 1280×800 |
| B133XW01 V7 | AUO | 13.3 | 1366×768 |
| B152EW01 V0 | AUO | 15.2 | 1280×854 |
| LP150X08-TLA7 | LG Display | 15.0 | 1024×768 |
| LQ133T1JW01 | SHARP | 13.3 | 2560×1440 |
| LTD111EV8X | TOSHIBA | 11.1 | 1366×768 |
| LTD133KX2S | TOSHIBA | 13.3 | 1280×800 |
| LTN140AT20-P02 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-802 | Samsung | 14.0 | 1366×768 |
| N133BGE-E31 | Innolux | 13.3 | 1366×768 |
