| PartNumber | B101EW01 V1 |
| Marca | AUO |
| mărimea | 10.1 |
| Aplicație | NBPC |
| Rezoluţie | 1280×720 |
| Compoziţie | LCM |
| Luminozitate | 180 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | B101EW01 V1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.1 inch |
| rezoluţie | 1280(RGB)×720 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 222.72×125.28 mm |
| contur | 243×146.5×3.6 mm |
| stilul formei | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| suprafaţă | Antiglare |
| luminozitatea | 180 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193145% |
| timp de raspuns | 12/4 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EAN01.3 | AUO | 10.1 | 1280×800 |
| B101EAN01.4 | AUO | 10.1 | 1280×800 |
| B101EAN01.5 | AUO | 10.1 | 1280×800 |
| B101EVN06.1 | AUO | 10.1 | 1280×800 |
| B101EVT05.0 | AUO | 10.1 | 1280×800 |
| B101EW01 V0 | AUO | 10.1 | 1280×720 |
| B101EW01 V1 | AUO | 10.1 | 1280×720 |
| B101EW02 V1 | AUO | 10.1 | 1280×720 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| B116XW03 V0 | AUO | 11.6 | 1366×768 |
| B121EW09 V3 HW0A | AUO | 12.1 | 1280×800 |
| LP133WF2-SPA1 | LG Display | 13.3 | 1920×1080 |
| LP140WH1-TPD1 | LG Display | 14.0 | 1366×768 |
| LP156WH2-TLA1 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLE1 | LG Display | 15.6 | 1366×768 |
| LTN160AT06-B01 | Samsung | 16.0 | 1366×768 |
| N150X3-L09 | Innolux | 15.0 | 1024×768 |
| N156HGE-LB1 | Innolux | 15.6 | 1920×1080 |
| N164HGE-L11 | Innolux | 16.4 | 1920×1080 |
