| PartNumber | AV123Z7T-A19-D8P0 |
| Marca | BOE |
| mărimea | 12.3 |
| Aplicație | Outdoor High Brightn |
| Rezoluţie | 1920×720 |
| Compoziţie | LCM, a-Si TFT-LCD |
| Luminozitate | |
| CR | 1100:1 |
| Culori | 16.7M |
| Iluminare de fundal | 9S4P |
| Interfață | LVDS |
| producător | BOE |
| numele modelului | AV123Z7T-A19-D8P0 |
| marimea ecranului | 12.3 inch |
| tipul de ecran | LCM, a-Si TFT-LCD |
| numărul de pixeli | 1920(RGB)×720 167PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 292.032 × 109.512 (H×V) |
| contur (mm) | 345.19 × 149.1 × 27.93 (H×V×D) |
| zona rama (mm) | - |
| tratament | Anti Fingerprint + Antiglare, Hard coating (3H) |
| luminanţă | 850 cd/m² (Typ.) |
| Raport de contrast | 1100 : 1 (Typ.) (TM) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| raspuns | 25 (Max.)(Tr+Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | IPS, Normally Black, Transmissive |
| adâncimea culorii | 16.7M 80% NTSC |
| lumina de fundal | 9S4P WLED , 50K hours , No Driver |
| masa | - |
| folosit pentru | Outdoor High Brightness Automotive Display |
| rată de reîmprospătare | 60Hz |
| touch screen | PCAP |
| tipul semnalului | LVDS (2 ch, 8-bit) , Connector 60 pins |
| alimentare cu tensiune | 3.3V (Typ.) |
| max. evaluări | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
