| PartNumber | AV080WSM-NW2 |
| Marca | BOE |
| mărimea | 8.0 |
| Aplicație | Automotive Display |
| Rezoluţie | 1024×600 |
| Compoziţie | LCM, a-Si TFT-LCD |
| Luminozitate | |
| CR | 800:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | 3S10P |
| Interfață | LVDS |
| producător | BOE |
| numele modelului | AV080WSM-NW2 |
| marimea ecranului | 8.0 inch |
| tipul de ecran | LCM, a-Si TFT-LCD |
| numărul de pixeli | 1024(RGB)×600 (WSVGA) 148PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 176.64 × 99.36 (H×V) |
| contur (mm) | 192.8 × 116.9 × 4.7 (H×V×D) |
| zona rama (mm) | 180.1 × 103.4 (H×V) |
| tratament | - |
| luminanţă | 600 cd/m² (Typ.) |
| Raport de contrast | 800 : 1 (Typ.) (TM) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| raspuns | 25 (Typ.)(Tr+Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | ADS, Normally Black, Transmissive |
| adâncimea culorii | 262K/16.7M 50% NTSC |
| lumina de fundal | 3S10P WLED , 30K hours , No Driver |
| masa | 176/180g (Typ./Max.) |
| folosit pentru | Automotive Display |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| tipul semnalului | LVDS (1 ch, 6/8-bit) , FPC 40 pins |
| alimentare cu tensiune | 3.3/11.5/21/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| max. evaluări | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
