| PartNumber | AM-1024768TTMQW-T00H |
| Marca | AMPIRE |
| mărimea | 10.4 |
| Aplicație | Industrial |
| Rezoluţie | 1024×768 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 900:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca | AMPIRE |
| model | AM-1024768TTMQW-T00H |
| dimensiunea diagonalei | 10.4 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 1024(RGB)×768 [XGA] 123PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 211.2(H)×158.4(V) mm |
| contur dim. | 236(H)×176.9(V) ×7.9(D) mm |
| zona rama | 214.8(H)×162.0(V) mm |
| tratament | Antiglare |
| luminanţă | 280 cd/m² (Typ.) |
| Raport de contrast | 900:1 (Typ.) (TM) |
| direcția vizualizării | 6 o'clock |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 75/75/75/75 (Typ.)(CR≥10) |
| mod de operare | TN, Normally White, Transmissive |
| culoare suport | 262K/16.7M |
| sursă de lumină | WLED [4 strings] , 30K hours , With LED Driver |
| greutate | 290g (Max.) |
| proiectat pentru | Industrial |
| rata de cadre | 60Hz |
| panou tactil | 4-wire Resistive Touch |
| tipul de interfață | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| alimentare electrică | 3.3V (Typ.) |
| mediu inconjurator | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
