| PartNumber | AM-1024768M2TMQW-T00H |
| Marca | AMPIRE |
| mărimea | 9.7 |
| Aplicație | IA |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM |
| Luminozitate | 425 |
| CR | |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AMPIRE |
| model de panou | AM-1024768M2TMQW-T00H |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 9.7 inch |
| rezoluţie | 1024(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 211.2×127.7 mm |
| contur | 236×175 mm |
| suprafaţă | |
| luminozitatea | 425 cd/m² (Typ.) |
| Raport de contrast | |
| culorile afișajului | 262K (6-bit), CIE193147% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 75/75/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S13PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| ED097OC1 | E Ink | 9.7 | 1200×825 |
| LP097X02-SLAA | LG Display | 9.7 | 1024×768 |
| LP097X02-SLQE | LG Display | 9.7 | 1024×768 |
| LQ097L1JY01A | SHARP | 9.7 | 2048×1536 |
| LTN097QL01-A02 | Samsung | 9.7 | 2048×1536 |
| LTN097XL01-A02 | Samsung | 9.7 | 1024×768 |
| TM097TDH02 | Tianma | 9.7 | 1024×768 |
| AA078AA01 | Mitsubishi | 7.8 | 800×300 |
| AC156GA01 | Mitsubishi | 15.6 | 1366×768 |
| EL320.240.36 ET CC | Lumineq | 5.7 | 320×240 |
| G156XW01 V1 | AUO | 15.6 | 1366×768 |
| LM12S49 | SHARP | 12.1 | 800×600 |
| LQ056A5GG01 | SHARP | 5.6 | 320×234 |
| LQ104S1DG31 | SHARP | 10.4 | 800×600 |
| LQ104V1DG71 | SHARP | 10.4 | 640×480 |
| MD286TT00-C1 | ORTUSTECH | 10.4 | 640×480 |
| TCG075VGLDA-G50 | Kyocera | 7.5 | 640×480 |
