| PartNumber | A070FW03 VB |
| Marca | AUO |
| mărimea | 7.0 |
| Aplicație | DPF |
| Rezoluţie | 480×234 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 400:1 |
| Culori | Full color |
| Iluminare de fundal | WLED |
| Interfață | Analog |
| marca panoului | AUO |
| model de panou | A070FW03 VB |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 480(RGB)×234 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 154.08×86.58 mm |
| contur | 164.9×100 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | Full color , CIE193148% |
| timp de raspuns | 4/12 (Typ.)(Tr/Td) |
| unghi de vedere | 65/65/40/65 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 3S6PWLEDWithout Driver |
| interfață de semnal | TFT Specific Analog RGB, 26 pins |
| tensiune de intrare | 3.3/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplicarea | DPF |
| A070FW01 | AUO | 7.0 | 480×234 |
| A070FW03 V1 | AUO | 7.0 | 480×234 |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| A070FW03 V4 | AUO | 7.0 | 480×234 |
| A070FW03 V6 | AUO | 7.0 | 480×234 |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| A070FW03 V8 | AUO | 7.0 | 480×234 |
| A070FW03 VB | AUO | 7.0 | 480×234 |
| A070FW03 VD | AUO | 7.0 | 480×234 |
| A070FW05 V1 | AUO | 7.0 | 480×234 |
| A101VW01 V0 | AUO | 10.1 | 800×480 |
| AT080TN03 V.7 | Innolux | 8.0 | 800×480 |
| AT102TN03 V.9 | Innolux | 10.2 | 800×480 |
| DLC0700EZG-1 | Other | 7.0 | 800×480 |
| EJ080NA-04B | Innolux | 8.0 | 1024×768 |
| HSD070IDW1-A00 | HannStar | 7.0 | 800×480 |
| HSD100IFW3-A00 | HannStar | 10.1 | 1024×600 |
| LTA070B0C0A | TOSHIBA | 7.0 | 480×234 |
| PM102ZY2 | E Ink | 10.2 | 1024×600 |
| TM104SDHG30 | Tianma | 10.4 | 800×600 |
