| PartNumber | A015AN05 V0 |
| Marca | AUO |
| mărimea | 1.5 |
| Aplicație | DSC |
| Rezoluţie | 280×220 |
| Compoziţie | LCM |
| Luminozitate | 170 |
| CR | 150:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | Serial RGB |
| marca panoului | AUO |
| model de panou | A015AN05 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 1.5 inch |
| rezoluţie | 280×220 |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 29.96×22.66 mm |
| contur | 37.06×34 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 170 cd/m² (Typ.) |
| Raport de contrast | 150:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 25/30 (Typ.)(Tr/Td) |
| unghi de vedere | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| tip lampa | 2S1PWLED |
| interfață de semnal | Serial RGB (6-bit) + SPI, 33 pins |
| tensiune de intrare | 3.3/3.3V (Typ.)(VCC/AVDD) |
| aplicarea | DSC |
