| PartNumber | TCG121XGLPAPNN-AN20-S |
| Marca | Kyocera |
| mărimea | 12.1 |
| Aplicație | Industrial |
| Rezoluţie | 1024×768 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 750:1 |
| Culori | 262K/16.2M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca | Kyocera |
| model | TCG121XGLPAPNN-AN20-S |
| dimensiunea diagonalei | 12.1 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 1024(RGB)×768 [XGA] 105PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 245.76(H)×184.32(V) mm |
| contur dim. | 260.5(H)×203.4(V) ×10.8(D) mm |
| zona rama | 249.0(H)×187.5(V) mm |
| tratament | Antiglare |
| luminanţă | 500 cd/m² (Typ.) |
| Raport de contrast | 750:1 (Typ.) (TM) |
| direcția vizualizării | Symmetry |
| timp de raspuns | 18/12 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10) |
| mod de operare | AWV, Normally Black, Transmissive |
| culoare suport | 262K/16.2M 50% NTSC |
| sursă de lumină | WLED , 50K hours , With LED Driver |
| greutate | 670g |
| proiectat pentru | Industrial |
| rata de cadre | 60Hz |
| panou tactil | Without |
| tipul de interfață | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| alimentare electrică | 3.3V (Typ.) |
| mediu inconjurator | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
