| PartNumber | RX430HD02-DC15 |
| Marca | ROGIN |
| mărimea | 43 |
| Aplicație | PID |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 1500 |
| CR | 3000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | ROGIN |
| model de panou | RX430HD02-DC15 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 43 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | Normally Black, Transmissive |
| Zonă activă | 941.184×529.416 mm |
| contur | 973.2×561.5×30 mm |
| suprafaţă | Antiglare (Haze 1%), Hard coating (3H) |
| luminozitatea | 1500 cd/m² (Typ.) |
| Raport de contrast | 3000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193168% |
| timp de raspuns | 6.5 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (2 ch, 8-bit), 51 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | PID |
