| PartNumber | PM058OX1 |
| Marca | E Ink |
| mărimea | 5.8 |
| Aplicație | PRO |
| Rezoluţie | 1280×768 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | No B/L |
| Interfață | Mini LVDS |
| marca panoului | PVI |
| model de panou | PM058OX1 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 5.8 inch |
| rezoluţie | 1280(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 126.72×74.88 mm |
| contur | 137.488×84.7 mm |
| suprafaţă | |
| adâncimea sticlei | 0.60+0.60 mm |
| transmisivitatea | 6.0% (Typ.)(with Polarizer) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 15/25 (Typ.)(Tr/Td) |
| unghi de vedere | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | Mini LVDS, 60 pins |
| tensiune de intrare | 3.3/3.3/12.5/18.0/-6.0V (Typ.)(VCC/VDD1/VDD2/VGG/VEE) |
| aplicarea | PRO |
