| PartNumber | NL192108BC18-06F |
| Marca | NLT |
| mărimea | 15.6 |
| Aplicație | Industrial Outdoor H |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 750:1 |
| Culori | 16.7M |
| Iluminare de fundal | 4 |
| Interfață | eDP |
| producător | NLT |
| numele modelului | NL192108BC18-06F |
| marimea ecranului | 15.6 inch |
| tipul de ecran | LCM , a-Si TFT-LCD |
| numărul de pixeli | 1920(RGB)×1080 (FHD) 141PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 344.16 × 193.59 (H×V) |
| contur (mm) | 363.8 × 215.9 × 16.2 (H×V×D) |
| zona rama (mm) | 347.55 × 196.75 (H×V) |
| tratament | Antiglare, Hard coating (3H) |
| luminanţă | 1500 cd/m² (Typ.) |
| Raport de contrast | 750 : 1 (Typ.) (TM) |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥10) |
| raspuns | 15/15 (Typ.)(Tr/Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | UA-SFT, Normally Black, Transmissive |
| adâncimea culorii | 16.7M 40% NTSC |
| lumina de fundal | 4 strings WLED , 50K hours , No Driver |
| masa | 1.05/1.15Kgs (Typ./Max.) |
| folosit pentru | Industrial Outdoor High Brightness |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| tipul semnalului | eDP (2 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
| alimentare cu tensiune | 3.3V (Typ.) |
| max. evaluări | Storage Temp.: -40 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
