| PartNumber | NL192108AC21-04 |
| Marca | NLT |
| mărimea | 18.5 |
| Aplicație | Industrial |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM , a-Si TFT-LCD |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| producător | NLT |
| marimea ecranului | 18.5 inch |
| numărul de pixeli | 1920(RGB)×1080 (FHD) 119PPI |
| zona activa (mm) | 408.96 × 230.04 (H×V) |
| zona rama (mm) | 413.4 × 234.0 (H×V) |
| luminanţă | 400 cd/m² (Typ.) |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥10) |
| vedere buna la | Symmetry |
| adâncimea culorii | 16.7M 72% NTSC |
| masa | 1.55/1.70Kgs (Typ./Max.) |
| rată de reîmprospătare | 60Hz |
| tipul semnalului | LVDS (2 ch, 8-bit) , 30 pins Connector |
| alimentare cu tensiune | 5.0V (Typ.) |
| max. evaluări | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| numele modelului | NL192108AC21-04 |
| tipul de ecran | LCM , a-Si TFT-LCD |
| aranjament | RGB Vertical Stripe |
| contur (mm) | 430.4 × 254.6 × 14 (H×V×D) |
| tratament | Antiglare, Hard coating (3H) |
| Raport de contrast | 1000 : 1 (Typ.) (TM) |
| raspuns | 12/13 (Typ.)(Tr/Td) ms |
| modul de lucru | UA-SFT, Normally Black, Transmissive |
| lumina de fundal | WLED , 50K hours , With LED Driver |
| folosit pentru | Industrial |
| touch screen | Without |
