| PartNumber | NL12880BC20-25F |
| Marca | NLT |
| mărimea | 12.1 |
| Aplicație | Industrial Outdoor H |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM, a-Si TFT-LCD |
| Luminozitate | |
| CR | 800:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | 3 |
| Interfață | LVDS |
| producător | NLT |
| numele modelului | NL12880BC20-25F |
| marimea ecranului | 12.1 inch |
| tipul de ecran | LCM, a-Si TFT-LCD |
| numărul de pixeli | 1280(RGB)×800 (WXGA) 124PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 261.12 × 163.2 (H×V) |
| contur (mm) | 277.7 × 180.6 × 9.2 (H×V×D) |
| zona rama (mm) | 266.1 × 168.2 (H×V) |
| tratament | Antiglare, Hard coating (3H) |
| luminanţă | 1600 cd/m² (Typ.) |
| Raport de contrast | 800 : 1 (Typ.) (TM) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| raspuns | 15 (Typ.)(Tr+Td) ms |
| vedere buna la | 6 o'clock |
| modul de lucru | TN, Normally White, Transmissive |
| adâncimea culorii | 262K/16.7M 50% NTSC |
| lumina de fundal | 3 strings WLED , 60K hours , No Driver |
| masa | 470g (Typ.) |
| folosit pentru | Industrial Outdoor High Brightness |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| tipul semnalului | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| alimentare cu tensiune | 3.3V (Typ.) |
| max. evaluări | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
