| PartNumber | MV215FHM-N20 |
| Marca | BOE |
| mărimea | 21.5 |
| Aplicație | Desktop Monitor Indu |
| Rezoluţie | 1920×1080 |
| Compoziţie | a-Si TFT-LCD, LCM |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca | BOE |
| model | MV215FHM-N20 |
| dimensiunea diagonalei | 21.5 inch |
| tip | a-Si TFT-LCD, LCM |
| format de pixeli | 1920(RGB)×1080 [FHD] 102PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 476.64(H)×268.11(V) mm |
| contur dim. | 485.3(H)×285.3(V) ×14.4(D) mm |
| zona rama | 479.3(H)×271.3(V) mm |
| tratament | Antiglare, Hard coating (3H) |
| luminanţă | 250 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) (TM) |
| direcția vizualizării | Symmetry |
| timp de raspuns | 14 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10) |
| mod de operare | ADS, Normally Black, Transmissive |
| culoare suport | 16.7M 73% NTSC |
| sursă de lumină | WLED [17S4P] , 30K hours , W/O Driver |
| greutate | 2.16Kgs (Typ.) |
| proiectat pentru | Desktop Monitor Industrial |
| rata de cadre | 60Hz |
| panou tactil | Without |
| tipul de interfață | LVDS (2 ch, 8-bit) , 30 pins Connector |
| alimentare electrică | 5.0V (Typ.) |
| mediu inconjurator | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| LM215WF2-SLC1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLK1 | LG Display | 21.5 | 1920×1080 |
| LM215WF5-SLA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF8-TLA1 | LG Display | 21.5 | 1920×1080 |
| LTM215HT04 | Samsung | 21.5 | 1920×1080 |
| M215HGE-L21 | Innolux | 21.5 | 1920×1080 |
| M215HW01 V5 | AUO | 21.5 | 1920×1080 |
| MT215DW01 V.1 | Innolux | 21.5 | 1920×1080 |
| MV215FHM-N30 | BOE | 21.5 | 1920×1080 |
| P215HVN01.0 | AUO | 21.5 | 1920×1080 |
