| PartNumber | MV185WHB-N20 |
| Marca | BOE |
| mărimea | 18.5 |
| Aplicație | Desktop Monitor |
| Rezoluţie | 1366×768 |
| Compoziţie | a-Si TFT-LCD, CELL |
| Luminozitate | |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | No |
| Interfață | LVDS |
| marca | BOE |
| model | MV185WHB-N20 |
| dimensiunea diagonalei | 18.5 inch |
| tip | a-Si TFT-LCD, CELL |
| format de pixeli | 1366(RGB)×768 [WXGA] 84PPI |
| configurație | RGB Vertical Stripe |
| Zonă activă | 409.8(H)×230.4(V) mm |
| contur dim. | 422.2(H)×244.1(V) ×1.32(D) mm |
| zona rama | - |
| tratament | Antiglare (Haze 25%), Hard coating (3H) |
| luminanţă | 0 cd/m² |
| Raport de contrast | 1000:1 (Typ.) (TM) |
| direcția vizualizării | Symmetry |
| timp de raspuns | 14 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10) |
| mod de operare | HADS, Normally Black, Transmissive |
| grosimea farfuriei | 0.50+0.50 mm |
| transmitanța | 6.0% (Typ.)(with Polarizer) |
| culoare suport | 16.7M 72% NTSC |
| sursă de lumină | No B/L |
| greutate | 327g (Typ.) |
| proiectat pentru | Desktop Monitor |
| rata de cadre | 60Hz |
| panou tactil | Without |
| detaliu d-ic | COF Built-in 2 source chips |
| tipul de interfață | LVDS (1 ch, 8-bit) , 30 pins Connector |
| alimentare electrică | 5.0V (Typ.) |
| mediu inconjurator | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| G185HAN01.0 | AUO | 18.5 | 1920×1080 |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| LTA185AT01 | Samsung | 18.5 | 1366×768 |
| LTM185AT02 | Samsung | 18.5 | 1366×768 |
| M185B1-L02 | Innolux | 18.5 | 1366×768 |
| M185XW01 VF | AUO | 18.5 | 1366×768 |
| MT185GW01 V.4 | Innolux | 18.5 | 1366×768 |
