| PartNumber | M270HVN02.1 |
| Marca | AUO |
| mărimea | 27.0 |
| Aplicație | DMPC |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 3000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | M270HVN02.1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 27.0 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | AMVA, Normally Black, Transmissive |
| Zonă activă | 597.6×336.15 mm |
| contur | 630.6×368.2×11 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 3000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 7/5 (Typ.)(Tr/Td) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 15S4PWLEDWithout Driver |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
| M270H1-L01 | Innolux | 27.0 | 1920×1080 |
| M270H3-L01 | Innolux | 27.0 | 1920×1080 |
| M270HGE-L10 | Innolux | 27.0 | 1920×1080 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| M270HGE-L30 | Innolux | 27.0 | 1920×1080 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| M270HVN02.0 | AUO | 27.0 | 1920×1080 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| M270HW02 V1 | AUO | 27.0 | 1920×1080 |
| LM250WF3-TLA1 | LG Display | 25.0 | 1920×1080 |
| LTM170ET01 | Samsung | 17.0 | 1280×1024 |
| LTM200KT12 | Samsung | 20.0 | 1600×900 |
| LTM215HT04 | Samsung | 21.5 | 1920×1080 |
| LTM230HL08 | Samsung | 23.0 | 1920×1080 |
| LTM240CT03 | Samsung | 24.0 | 1920×1200 |
| LTM270TT01 | Samsung | 27.0 | 2048×1152 |
| M238HVN01.0 | AUO | 23.8 | 1920×1080 |
| M280DGJ-L30 | Innolux | 28.0 | 3840×2160 |
| MT190AW02 V.V | Innolux | 19.0 | 1440×900 |
