| PartNumber | M215HJJ-P3N |
| Marca | Innolux |
| mărimea | 21.5 |
| Aplicație | Desktop Monitor |
| Rezoluţie | 1920×1080 |
| Compoziţie | CELL, a-Si TFT-LCD |
| Luminozitate | |
| CR | 3000:1 |
| Culori | 16.7M |
| Iluminare de fundal | No |
| Interfață | LVDS |
| producător | Innolux |
| numele modelului | M215HJJ-P3N |
| marimea ecranului | 21.5 inch |
| tipul de ecran | CELL, a-Si TFT-LCD |
| numărul de pixeli | 1920(RGB)×1080 (FHD) 102PPI |
| aranjament | RGB Vertical Stripe |
| zona activa (mm) | 476.064 × 267.786 (H×V) |
| contur (mm) | 487.456 × 270.18 × 1.29 (H×V×D) |
| zona rama (mm) | - |
| tratament | Antiglare, Hard coating (3H) |
| luminanţă | 0 cd/m² |
| Raport de contrast | 3000 : 1 (Typ.) (TM) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥20) |
| raspuns | 20/5 (Typ.)(Tr/Td) ms |
| vedere buna la | Symmetry |
| modul de lucru | MVA, Normally Black, Transmissive |
| grosimea sticlei | 0.50+0.50 mm |
| transmisivitatea | 4.4% (Typ.)(with Polarizer) |
| adâncimea culorii | 16.7M |
| lumina de fundal | No B/L |
| masa | TBD |
| folosit pentru | Desktop Monitor |
| rată de reîmprospătare | 60Hz |
| touch screen | Without |
| lista de drivere ic | Built-in COF 6 source chips |
| tipul semnalului | LVDS (2 ch, 8-bit) , Connector 30 pins |
| alimentare cu tensiune | 5.0V (Typ.) |
| max. evaluări | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
