| PartNumber | LTY400HF06 |
| Marca | Samsung |
| mărimea | 40 |
| Aplicație | LCTV |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 5000:1 |
| Culori | 1.07B |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | SAMSUNG |
| model de panou | LTY400HF06 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 40 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | S-PVA, Normally Black, Transmissive |
| Zonă activă | 885.6×498.15 mm |
| contur | 952×551×61.2 mm |
| suprafaţă | Antiglare (Haze 4.5%), Hard coating (3H) |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 5000:1 (Typ.) |
| culorile afișajului | 1.07B (8-bit + Hi-FRC), CIE193172% |
| timp de raspuns | 12/6 (Typ.)(Tr/Td); 6.5 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 10 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (2 ch, 10-bit), 55 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | LCTV |
