| PartNumber | LTN160HT01-A02 |
| Marca | Samsung |
| mărimea | 16.0 |
| Aplicație | NBPC |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | SAMSUNG |
| model de panou | LTN160HT01-A02 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 16.0 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 353.28×198.72 mm |
| contur | 365×214 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Glare (Haze 0%), Hard coating (3H) |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193160% |
| timp de raspuns | 8 (Typ.)(Tr+Td) |
| unghi de vedere | 75/75/60/55 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (2 ch, 6-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| HN116WX1-203 | BOE | 11.6 | 1366×768 |
| LP125WH2-TLB1 | LG Display | 12.5 | 1366×768 |
| LP156WF1-TLE1 | LG Display | 15.6 | 1920×1080 |
| LP171WU1-TLA5 | LG Display | 17.1 | 1920×1200 |
| LQ133K1LA4A | SHARP | 13.3 | 1280×800 |
| LTD111EXCA | TOSHIBA | 11.1 | 1366×768 |
| LTN150PF-L03 | Samsung | 15.0 | 1400×1050 |
| LTN154U1-L02 | Samsung | 15.4 | 1920×1200 |
| LTN173KT01-J01 | Samsung | 17.3 | 1600×900 |
| N140BGE-EA3 | Innolux | 14.0 | 1366×768 |
