| PartNumber | LTN141AT13-H01 |
| Marca | Samsung |
| mărimea | 14.1 |
| Aplicație | NBPC |
| Rezoluţie | 1280×800 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 300:1 |
| Culori | 262K |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | SAMSUNG |
| model de panou | LTN141AT13-H01 6 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 14.1 inch |
| rezoluţie | 1280(RGB)×800 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 303.36×189.6 mm |
| contur | 319.5×205.5×5.5 mm |
| stilul formei | Wedge (PCBA Bent, Depth ≥5.2mm) |
| suprafaţă | Glare (Haze 0%), Hard coating (3H) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 300:1 (Min.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| LTN141AT05-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT05-G03 | Samsung | 14.1 | 1280×800 |
| LTN141AT08-304 | Samsung | 14.1 | 1280×800 |
| LTN141AT12-W03 | Samsung | 14.1 | 1280×800 |
| LTN141AT13-H01 | Samsung | 14.1 | 1280×800 |
| LTN141AT15-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-002 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-003 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-B03 | Samsung | 14.1 | 1280×800 |
| B125XW02 V0 | AUO | 12.5 | 1366×768 |
| B133HAN02.1 | AUO | 13.3 | 1920×1080 |
| B140HAN01.2 | AUO | 14.0 | 1920×1080 |
| B156HAK01.0 | AUO | 15.6 | 1920×1080 |
| B173HW01 V5 | AUO | 17.3 | 1920×1080 |
| LP140WH4-TLD1 | LG Display | 14.0 | 1366×768 |
| LQ133T1JW02 | SHARP | 13.3 | 2560×1440 |
| LTD121EDFN | TOSHIBA | 12.1 | 1024×768 |
| LTD121EXPD | TOSHIBA | 12.1 | 1280×800 |
| N141C1-L05 | Innolux | 14.1 | 1440×900 |
