| PartNumber | LTI460AA01-001 |
| Marca | Samsung |
| mărimea | 46 |
| Aplicație | PID |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 700 |
| CR | 2000:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | SAMSUNG |
| model de panou | LTI460AA01-001 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 46 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | S-PVA, Normally Black, Transmissive |
| Zonă activă | 1018.35×572.544 mm |
| contur | 1047.4×600.6×59.3 mm, Videowall Seam 29.0 mm |
| suprafaţă | Glare (Haze 0%), Hard coating (3H) |
| luminozitatea | 700 cd/m² (Typ.) |
| Raport de contrast | 2000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 10/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 24 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (1 ch, 8-bit), 30 pins |
| tensiune de intrare | 12.0V (Typ.) |
| aplicarea | PID |
| LTA460HT-LH3 | Samsung | 46 | 1920×1080 |
| LTI460AA01-001 | Samsung | 46 | 1366×768 |
| LTI460AA03 | Samsung | 46 | 1366×768 |
| LTI460AA04 | Samsung | 46 | 1366×768 |
| LTI460AA05 | Samsung | 46 | 1366×768 |
| LTI460AN01 | Samsung | 46 | 1366×768 |
| LTI460AP01 | Samsung | 46 | 1366×768 |
| LTI460AP01-101 | Samsung | 46 | 1366×768 |
| LTI460HN08 | Samsung | 46 | 1920×1080 |
| V460H1-LS1 Rev.C6 | Innolux | 46 | 1920×1080 |
| LD320WUD-SBA1 | LG Display | 31.5 | 1920×1080 |
| LD470EUP-SEB1 | LG Display | 47 | 1920×1080 |
| LTI320AP02 | Samsung | 31.5 | 1366×768 |
| LTI400HA03 | Samsung | 40 | 1920×1080 |
| LTI460AP01 | Samsung | 46 | 1366×768 |
| LTI550HN03 | Samsung | 55 | 1920×1080 |
| LTI820HA01 | Samsung | 82 | 1920×1080 |
| ND168TXP01 | 16.8 | 1366×378 | |
| P460HVN03.0 | AUO | 46 | 1920×1080 |
| P650HVF01.0 | AUO | 65 | 1920×1080 |
