| PartNumber | LQ125T1JW02 |
| Marca | SHARP |
| mărimea | 12.5 |
| Aplicație | NBPC |
| Rezoluţie | 2560×1440 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca panoului | SHARP |
| model de panou | LQ125T1JW02 |
| tip panou | IGZO TFT-LCD , LCM |
| dimensiunea panoului | 12.5 inch |
| rezoluţie | 2560(RGB)×1440 , Quad-HD |
| modul de afișare | Normally Black, Transmissive |
| suprafaţă | |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLED |
| interfață de semnal | eDP (4 Lanes) |
| rohs: | |
| aplicarea | NBPC |
